4 flutes flattened end mills for all kind of materials
Type:4 flutes flattened end mill
Material:Tungsten carbide
Hardness:HRC≤45°
Coating:AlTiN
4 Flutes flattened end mills for general cutting all kinds of materials
| Flutes No. | 2/4 Flutes |
| Material | Tungsten carbide |
| Coating | AlTiN |
| Helix Angle | 35° |
| Hardness | HRC45° |
| Customized | Accept |
| Smooth Finish | Highly polished |
| Feature | Excellent chip evacuation |
| Measurement | Metric |
Technology&Application
Incorporate latest molding, coating, edge preparation,and other manufacturing technology. Provide superior performance.
Coatings provide high-speed capability and are engineered from finishing to heavy roughing,The post-coat treatment reduces coating stresses, improves coating adhesion, minimises microchipping and edge build-up, and improves workpiece finish.Coated surface enable to get Longer tools life.
Application areas: Machining of cast iron, nonferrous alloy, chill cast iron, hard steel, stainless steel, plastic materials, fiberglass, carbon fiber and other non-metallic.
Served industries: Aerospace,Transportation,Medical Equipment,Military Manufacturing,Mold Development,etc.
| Item No.: | Edge diameter | Edge length | Overall length | Shank diameter |
| 4F*1*3*50S4 | 1 | 3 | 50 | 4 |
|
4F*1.5*4*50S4 |
1.5 | 4 | 50 | 4 |
|
4F*2*6*50S4 |
2 | 6 | 50 | 4 |
|
4F*2.5*8*50S4 |
2.5 | 8 | 50 | 4 |
|
4F*3*8*50S4 |
3 | 8 | 50 | 4 |
|
4F*3.5*10*50S4 |
3.5 | 10 | 50 | 4 |
|
4F*4*10*50S4 |
4 | 10 | 50 | 4 |
|
4F*5*13*50S6 |
5 | 13 | 50 | 6 |
|
4F*6*15*50 |
6 | 15 | 50 | 6 |
|
4F*7*20*60 |
7 | 20 | 60 | 8 |
|
4F*8*20*60 |
8 | 20 | 60 | 8 |
|
4F*9*25*75 |
9 | 25 | 75 | 10 |
|
4F*10*25*75 |
10 | 25 | 75 | 10 |
|
4F*11*30*75 |
11 | 30 | 75 | 12 |
|
4F*12*30*75 |
12 | 30 | 75 | 12 |
|
4F*14*35*80 |
14 | 35 | 80 | 14 |
|
4F*16*40*100 |
16 | 40 | 100 | 16 |
|
4F*18*40*100 |
18 | 40 | 100 | 18 |
|
4F*20*40*100 |
20 | 40 | 100 | 20 |
|
4F*21*50*100 |
21 | 50 | 100 | 21 |
|
4F*22*50*100 |
22 | 50 | 100 | 22 |
|
4F*23*50*100 |
23 | 50 | 100 | 23 |
|
4F*24*50*100 |
24 | 50 | 100 | 24 |
|
4F*25*50*100 |
25 | 50 | 100 | 25 |
|
4F*26*50*100 |
26 | 50 | 100 | 26 |
|
4F*27*50*100 |
27 | 50 | 100 | 27 |
|
4F*28*50*100 |
28 | 50 | 100 | 28 |
|
4F*29*50*100 |
29 | 50 | 100 | 29 |
|
4F*30*50*100 |
30 | 50 | 100 | 30 |
Service We Can Offer You:
♣Quick Response:Your inquiry will be replied within 24 hours.
♣High Quality:Well-trained workers and more than 10 years experience.
♣Competitive Price:Directly from factory to save your money.
♣Short Lead Time:Being efficient:3-7 days for samples and 10-35 days for quantity orders.
♣Flexibility:Small orders are acceptable for quick delivery and to help you reduce stock cost.
♣OEM:Custom fabrication according to your drawings ,samples or designs.
