Tungsten Carbide Strip

High-hardness HRA86-92
Common sizes have stock
Customized shape available
Good wear resistance, corrosion resistance, and bending resistance

EMAIL

Tungsten Carbide is a sintered metallurgical product of powder form. It is manufactured in vacuum or Hydrogen reduction furnaces with refractory Tungsten material (WC) micron powder as the main ingredient and Cobalt (Co), Nickel (Ni), or Molybdenum (Mo) as the binder.

Tungsten carbide Strip is widely known as one kind of carbide cutting tools. Tungsten carbide strip is available for different grinding geometric parameters and suitable for both cutting materials and nonmetal materials, also it can be applied to conventional, carbide inserts, semi-automatic lathe, automatic lathe and planning machine to work grooves and operate cutting, etc.We have tungsten carbide strips in different size and grades in stock.

Size Example List

Sizes
Rough tolerance(mm)
Length Width Thickness
330X2X(2-25) +1.0/+0 +0.6/+0.3 +0.5/+0.2
330x3(3-32) +1.0/+0 +0.6/+0.3 +0.5/+0.2
330X4x(4-35) +1.0/+0 +0.6/+0.3 +0.5/+0.2
330X5(5-35) +1.0/+0 +0.6/+0.3 +0.5/+0.2
330x6(6-35) +1.0/+0 +0.6/+0.3 +0.5/+0.2
330X7X7 +1.0/+0 +0.6/+0.3 +0.5/+0.2
330X8X8 +1.0/+0 +0.6/+0.3 +0.5/+0.2
330X10X10 +1.0/+0 +0.6/+0.3 +0.5/+0.2
330X12X12 +1.0/+0 +0.6/+0.3 +0.5/+0.2
330X14X14 +1.0/+0 +0.6/+0.3 +0.5/+0.2
Grade Example list

Grade

Density(g/cm3)

±0.1

HRA±0.3 TRS(N/mm2) Grain Size(um)
YG6 14.9 90 2100 1.2-1.6
YG6A 14.9 91.5 2300 1.0-1.2
YG8 14.7 89.5 2200 1.2-1.6
YG11 14.4 87.5 2500 1.6-2.0
YG15 14 86.5 3000 1.6-2.0
YG20 13.8 86 3500 1.0-1.2

Tungsten carbide strip description

1.The tungsten carbide strip with fine compactness,and the strength and hardness are both

Comply with ISO standard.

2.The purity of our raw materials reach to 99.95%, which caused it has less Impurity and the

physical properties of the strips are more stable.

3.Using spray drying technology, the material is full sealed conditions with high purity nitrogen protection, which effectively reduce the mixing process in the preparation of the possibility of oxygen, caused the material has better purity and not easy to be dirty;

4.300Mpa static press,which can effectively prevent defects and make the strips density more uniform.

5.Using cryogenic treatment technology, which make the internal microstructure of the strip can be improved, the internal stress can be greatly reduced, and then the possibility of cracks in the cutting process is effectively avoided.
